Frame Type Forging Manipulator
65238 USD ($)/Set
Product Details:
- Product Type Forged Products
- Material Steel
- Technology Forging
- Color Green
- Click to View more
X
Frame Type Forging Manipulator Price And Quantity
- 1 Set
- 65238 USD ($)/Set
Frame Type Forging Manipulator Product Specifications
- Steel
- Forged Products
- Green
- Forging
Frame Type Forging Manipulator Trade Information
- 5 Set Per Month
- 60 Days
- Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
Product Description
The frame type forging manipulator comprises rotating movement manipulator and transactional movement manipulator. Moreover, the frame type transactional movement manipulator actions include manipulator traveling with front and rear side of clamping that goes up and down, wherein the clamping device is inclined.
Technical Specification
|
Model |
T31DHH-1 |
T31DHZ-1 |
T31DHH-2 |
T31DHZ-2 |
T31DHH-3 |
T31DHZ-3 |
T31DHH-5 |
T31DHZ-5 |
T31DHZ-8 |
T31DHZ-10 |
T31DHZ-15 |
|
|
Nominal Loading Force |
KN |
10 |
10 |
20 |
20 |
30 |
30 |
50 |
50 |
80 |
100 |
150 |
|
Holding Moment |
KNM |
20 |
20 |
48 |
48 |
60 |
60 |
120 |
120 |
200 |
250 |
300 |
|
Holding Diameter Range |
mm |
60-420 |
60-420 |
100-600 |
100-600 |
150-650 |
150-650 |
150-800 |
150-800 |
180-1000 |
170-1030 |
240-1200 |
|
Min Clamp Rod Height |
mm |
650 |
650 |
750 |
620 |
750 |
650 |
1050 |
780 |
800 |
800 |
800 |
|
Clamp Body Vertical Stroke |
mm |
550 |
550 |
750 |
880 |
550 |
650 |
700 |
720 |
1000 |
1000 |
1080 |
|
Clamp Rod Vertical Movement Speed |
m/min |
6 |
6 |
7 |
7 |
6 |
6 |
5 |
5 |
6 |
6 |
5 |
|
Clamp Up Pitch Angle |
Degree |
7 |
7 |
10 |
10 |
10 |
10 |
7 |
7 |
7 |
7 |
10 |
|
Clamp Down Pitch Angle |
Degree |
15 |
15 |
15 |
Touch Ground |
Touch Ground |
Touch Ground |
12 |
Touch Ground |
Touch Ground |
12 |
7 |
|
Clamp Rotating Speed |
r/min |
20 |
20 |
25 |
25 |
20 |
20 |
18 |
18 |
20 |
15 |
15 |
|
Manipulator Travelling Speed |
m/min |
40 |
40 |
40 |
40 |
26 |
26 |
25 |
25 |
20 |
15 |
20 |
|
Rail Distance |
mm |
2236 |
2236 |
2236 |
2236 |
2300 |
2300 |
2300 |
2300 |
2500 |
2800 |
3000 |
