Send InquiryFully Hydraulic Forging Hammer Power Head
Price 1008571 USD ($)/ Set
Fully Hydraulic Forging Hammer Power Head Specification
- Process
- Hot Closed Die Forging
- Product Type
- Forged Equipment
- Material
- Carbon Steel
- Technology
- Forging
- Application
- Auto Parts
- Weight
- 100000 Kilograms (kg)
- Color
- Green
Fully Hydraulic Forging Hammer Power Head Trade Information
- Minimum Order Quantity
- 1 Set
- FOB Port
- Tianjin port
- Supply Ability
- 5 Sets, , Per Month
- Delivery Time
- 60 Days
- Sample Available
- Yes
- Sample Policy
- Contact us for information regarding our sample policy
- Packaging Details
- Wooden case
- Main Export Market(s)
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- CE
About Fully Hydraulic Forging Hammer Power Head
The fully hydraulic hammer power head is appropriate for steam hammer conversion, electro hydraulic forging hammer and air compressor forging hammer. It makes old forging hammer fully hydraulic forging with small investment and high benefit through conversion.
How to do conversion on old forging hammer:
a. For steam hammer and air compressor forging hammer: It can be used through anvil block and hammer frame(with original type or X guide) of original hammer. To match fully hydraulic power head, electro control system and hydraulic station
b. For electro hydraulic forging hammer: It can used through using hammer frame, anvil block, tup, hydraulic station and electro control system of original hammer to match new fully hydraulic power head.
Hydraulic hammer head features:
- Short conversion cycle
- Low energy consumption
- High hitting frequency
- Light operating force
- Low labor intensity
Main technical specification of hydraulic hammer head
|
Item |
Unit |
C86YT- 25 (1T) |
C86YT- 50(2T) |
C86YT- 75(3T) |
C86YT- 125(5T) |
C86YT- 200(8T) |
C86YT- 250(10T) |
C86YT- 400(16T) |
C86YT- 450(18T) |
|
Below energy |
KJ |
25 |
50 |
70 |
125 |
200 |
250 |
400 |
450 |
|
Ram weight |
kg |
1000 |
2000 |
3000 |
5000 |
8000 |
10000 |
16000 |
18000 |
|
Max.stroke |
mm |
1000 |
1200 |
1250 |
1300 |
1350 |
1400 |
1500 |
1500 |
|
Hit frequency |
min-1 |
55-70 |
55-70 |
55-70 |
55-65 |
55-65 |
50-60 |
50-55 |
45-50 |
|
Motor power |
kw |
75x1 |
75x2 |
75x3 |
75x4 |
75x5 |
75x6 |
75x8 |
75x10 |
|
Min height of close die (without dovetail) |
mm |
220 |
260 |
350 |
400 |
430 |
450 |
500 |
500 |
