Pneumatic Forging Hammer Forge Balls

Pneumatic Forging Hammer Forge Balls

21000 USD ($)/Set

Product Details:

  • Product Type Pneumatic Forging Hammer Forge Balls
  • General Use Industrial
  • Material Steel Alloy
  • Computerized No
  • Automatic Yes
  • Surface Treatment Polishing
  • Feature High Efficiency High Performance ECO Friendly
  • Click to View more
X

Pneumatic Forging Hammer Forge Balls Price And Quantity

  • 21000 USD ($)/Set
  • 1 Set

Pneumatic Forging Hammer Forge Balls Product Specifications

  • Pneumatic Forging Hammer Forge Balls
  • Yes
  • Blue
  • Industrial
  • 1 Year
  • High Efficiency High Performance ECO Friendly
  • No
  • Polishing
  • Steel Alloy

Pneumatic Forging Hammer Forge Balls Trade Information

  • 50 Set Per Year
  • 2 Months
  • Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa

Product Description

The Pneumatic hammer has fust running capacity and can forge large range size steel balls. The steel ball impact resistance is excellent and ensures strong toughness with good wear resistance and is non breakable. The heating metal billet is to be 1050 Degree  (error 50  Degree). The hammer eliminates the metal casting defect and hence optimizes the microstructure. The metal flow is also kept intact and the forging is better.

Application of Forging Balls

The forged steel ball is used in large mines , aluminum oxide, gold, magnetic materials and many similar industries of ball mill and rod mill equipment.

Advantages

  • Forging steel balls diameter range is 20mm-250mm
  • Surface hardness is 55-56HRC along-with volume hardness of 50-63HRC
  • Impact toughness over 12J/cm2 which is on higher side
  • Non breakable
  • Crush resistance is 10 times better than the general casting balls
  • No deformation

One type of pneumatic forging hammer especially for forging balls are designed to reduce the maintenance cost of forging balls. It uses the round ram without guide.

Technical Specification

Max.forged steel ball OD
mm

Hammer model

Output per shift

(pieces)

Weight per ball

(kg)

Output per shift

(Ton)

70

C41-150

2880

1.41

4.06

90

C41-250

1920

3

5.76

110

C41-400

1440

5.47

7.88

130

C41-560

1152

9.03

10.4

150

C41-750

960

11.27

10.82

200

C41-1000

480

32.88

15.78

250

C41-2000

480

64.22

30.83
